Lead time:39 to 50days

The robust, professional-grade CoreXY workhorse. Featuring a fixed gantry and a 3-point independent Z-axis moving bed, the Voron Trident is engineered for heavy-duty reliability and high-temperature advanced manufacturing.

Product Overview

The Voron Trident is designed for continuous, reliable production. Unlike the flying gantry of the 2.4, the Trident utilizes a stationary XY gantry and a sturdy, 3-point lead-screw-driven Z-axis bed. This traditional but highly optimized mechanical layout drastically reduces complexity while maintaining blistering CoreXY print speeds and exceptional surface quality.

Fully enclosed and natively powered by Klipper firmware, the Trident excels at processing demanding materials. Whether you are dialing in pressure advance for flawless PETG and TPU, or batch-manufacturing structural parts in ABS and CF-PLA, the Trident provides an incredibly rigid, industrial-grade platform.

Key Features

Triple Z-Axis Bed: Three independent high-torque stepper motors and integrated lead screws provide true automated bed tramming and leveling.

Stationary CoreXY Gantry: A fixed top gantry ensures absolute rigidity at high accelerations, virtually eliminating frame resonance.

Advanced Material Capability: The enclosed chamber design traps heat, natively supporting warp-free printing of ABS, PC, Nylon, and carbon-fiber composites.

Premium Motion System: Equipped with precision linear rails, genuine guide carriages, and Gates belts for flawless, artifact-free motion.

Klipper Native: Designed from the ground up to leverage Klipper firmware for advanced input shaping, custom UI themes, and complete web-based control.

Technical Specifications

SpecificationDetails

Motion KinematicsCoreXY (Fixed Gantry, Moving Bed)

Available Build Volumes250³ mm / 300³ mm / 350³ mm

Z-Axis Drive3x Independent Lead Screws

Extrusion SystemDirect Drive (StealthBurner standard)

Max Hotend Temp~300°C (Hotend dependent)

Max Bed Temp110°C+ (Cast aluminum bed with silicone heater)

FirmwareKlipper

Ideal FilamentsABS, ASA, CF-PLA, PETG, TPU, Nylon
